Thông số kĩ thuật

• Measurement accuracy:1%
• Capacitance measuring scope: 0.01 pF - 10uF
• The minimum resolution: 0.01 pF
• Big Capacitance measuring scope:1uF-100mF
• The minimum resolution:0.01UF
• Inductance measuring scope: 0.001 uH - 100mH
• Big inductance measuring scope: 0.001 mH - 100H
• The minimum resolution: 0.001uH
• Test frequency: L/C about 500KHZ Big inductance about 500HZ(can display current test frequency value)
• Effective display digits: 4 digits - LCD display mode: 1602
• Supply supply: miniUSB interface 4X1.5V 5# battey Or DC5V adaptor - Note: before testing a Capacitance or inductance,Please reset to zero,if you test a Capacitance,and find the value is unstable,that meaning this capacitance's stability or frequency characteristic is very poor
• Weight: about 500g
