Features:
1>. Bluetooth wireless connection.Longest communication distance 20 meter.
2>. Support decoding function.
3>. Pairing voice prompts.
4>. Easy to use,just need power and headset.
5>. Small size.
6>. Simple wiring.
7>. Stable output.
Parameters:
1>. Mode: XY-BT-MINI
2>. Work voltage: DC 3.7V-5V/Micro USB
3>. Output Power: 3W*2
4>. Audio Socket: 3.5mm
5>. Size: 68*48*10mm
6>. SNR: 90dB
7>. THD+N: -70dB
8>. Crosstalk: -86dB
9>. DNR: 91dB
10>. Support Profile: A2DP/AVCTP/AVDTP/AVRCP/HFP
11>. LOS: >15m
12>. Bluetooth version: 4.1
Use Manual:
1>. Connect input power from Micro USB or pads.The power indicator LED will ON.
2>. Connect to headset or speakers or amplifier.
3>. It will into Bluetooth mode and it is ready to pair after power on.
4>. Bluetooth name is ‘ XY_BT ’.
5>. Pair and connect to Bluetooth.You will hear the prompt voice ”The Bluetooth device is connected successfully”.
6>. Play music.
Application:
1>. Speaker
2>. Smart home
3>. Voice prompts
4>. Hotel
5>. Mall
6>. Toy
Frequency asked questions:
1>. Is the voice prompt in English?
Q : Yes,It is.
2>. Can delete the voice prompt?
Q : No,it can not.
3>. Can playback priority be set?
Q : No,it can not.
Package:
1>.1pcs XY-BT-MINI Bluetooth decoder
