Manufacturer |
ON Semiconductor |
FET Type |
N-Channel |
Voltage - Breakdown (V(BR)GSS) |
25V |
Drain to Source Voltage (Vdss) |
25V |
Current - Drain (Idss) @ Vds (Vgs=0) |
1mA @ 15V |
Voltage - Cutoff (VGS off) @ Id |
500mV @ 10nA |
Input Capacitance (Ciss) (Max) @ Vds |
7pF @ 15V |
Power - Max |
310mW |
Operating Temperature |
135°C (TJ) |
Mounting Type |
Through Hole |
Package / Case |
TO-226-3, TO-92-3 (TO-226AA) |
Supplier Device Package |
TO-92-3 |
Base Part Number |
2N5457 |
