Type |
Description |
Manufacturer |
Vishay Semiconductor Diodes Division |
Diode Configuration |
1 Pair Common Cathode |
Diode Type |
Standard |
Voltage - DC Reverse (Vr) (Max) |
400V |
Current - Average Rectified (Io) (per Diode) |
15A |
Voltage - Forward (Vf) (Max) @ If |
1.3V @ 15A |
Speed |
Fast Recovery =< 500ns, > 200mA (Io) |
Reverse Recovery Time (trr) |
50ns |
Current - Reverse Leakage @ Vr |
10µA @ 400V |
Operating Temperature - Junction |
-55°C ~ 150°C |
Mounting Type |
Through Hole |
Package / Case |
TO-3P-3, SC-65-3 |
Supplier Device Package |
TO-3P |
Base Part Number |
FEP30 |
