Manufacturer |
Sanken |
FET Type |
4 N-Channel (Half Bridge) |
FET Feature |
Logic Level Gate |
Drain to Source Voltage (Vdss) |
60V |
Current - Continuous Drain (Id) @ 25°C |
5A |
Rds On (Max) @ Id, Vgs |
300mOhm @ 3A, 4V |
Vgs(th) (Max) @ Id |
2V @ 250µA |
Gate Charge (Qg) (Max) @ Vgs |
- |
Input Capacitance (Ciss) (Max) @ Vds |
320pF @ 10V |
Power - Max |
4.8W |
Operating Temperature |
150°C (TJ) |
Mounting Type |
Through Hole |
Package / Case |
15-SIP Exposed Tab, Formed Leads |
Supplier Device Package |
15-ZIP |
