Manufacturer |
ON Semiconductor |
Diode Type |
Standard |
Voltage - DC Reverse (Vr) (Max) |
1000V |
Current - Average Rectified (Io) |
2A |
Voltage - Forward (Vf) (Max) @ If |
1.15V @ 2A |
Speed |
Standard Recovery >500ns, > 200mA (Io) |
Reverse Recovery Time (trr) |
2µs |
Current - Reverse Leakage @ Vr |
1µA @ 1000V |
Capacitance @ Vr, F |
30pF @ 4V, 1MHz |
Mounting Type |
Surface Mount |
Package / Case |
DO-214AA, SMB |
Supplier Device Package |
DO-214AA (SMB) |
Operating Temperature - Junction |
-65°C ~ 150°C |
Base Part Number |
S2M |
