Manufacturer |
Infineon Technologies |
Structure |
Series Connection - All SCRs |
Number of SCRs, Diodes |
2 SCRs |
Voltage - Off State |
1.6kV |
Current - On State (It (AV)) (Max) |
500A |
Current - On State (It (RMS)) (Max) |
900A |
Voltage - Gate Trigger (Vgt) (Max) |
2.2V |
Current - Gate Trigger (Igt) (Max) |
250mA |
Current - Non Rep. Surge 50, 60Hz (Itsm) |
17000A @ 50Hz |
Current - Hold (Ih) (Max) |
300mA |
Operating Temperature |
-40°C ~ 125°C |
Mounting Type |
Chassis Mount |
Package / Case |
Module |
