Type |
Description |
Manufacturer |
ON Semiconductor |
Diode Type |
Standard |
Voltage - DC Reverse (Vr) (Max) |
1200V |
Current - Average Rectified (Io) |
30A |
Voltage - Forward (Vf) (Max) @ If |
3.2V @ 30A |
Speed |
Fast Recovery =< 500ns, > 200mA (Io) |
Reverse Recovery Time (trr) |
85ns |
Current - Reverse Leakage @ Vr |
250µA @ 1200V |
Capacitance @ Vr, F |
- |
Mounting Type |
Through Hole |
Package / Case |
TO-247-2 |
Supplier Device Package |
TO-247-2 |
Operating Temperature - Junction |
-65°C ~ 175°C |
