Manufacturer: | Fairchild Semiconductor |
Product Category: | Bipolar Small Signal |
RoHS: | Yes |
Configuration: | Single |
Transistor Polarity: | PNP |
Mounting Style: | Through Hole |
Package / Case: | TO-92 |
Collector- Emitter Voltage VCEO Max: | 160 V |
Emitter- Base Voltage VEBO: | - 6 V |
Continuous Collector Current: | - 1 A |
Maximum DC Collector Current: | - 1 A |
Maximum DC Collector Current: | 1 A |
Power Dissipation: | 0.9 W |
Maximum Operating Frequency: | 50 MHz |
Maximum Operating Temperature: | + 150 C |
DC Collector/Base Gain hfe Min: | 60 |
Minimum Operating Temperature: | - 55 C |
Factory Pack Quantity: | 2000 |
Part # Aliases: | KSA1013 |
