Manufacturer |
ON Semiconductor |
Transistor Type |
NPN |
Current - Collector (Ic) (Max) |
3A |
Voltage - Collector Emitter Breakdown (Max) |
60V |
Vce Saturation (Max) @ Ib, Ic |
1V @ 300mA, 3A |
Current - Collector Cutoff (Max) |
100µA (ICBO) |
DC Current Gain (hFE) (Min) @ Ic, Vce |
100 @ 500mA, 5V |
Power - Max |
30W |
Frequency - Transition |
3MHz |
Operating Temperature |
150°C (TJ) |
Mounting Type |
Through Hole |
